64
Output Format with 22 Characters
When data with an ID code is output, the ID code consisting of 6 characters
precedes the data with the 16-character format. These 6 characters identify the
following value.
12345678910111213141516171819202122
IIIIII+*DDDDDDDD*UUUCRLF
*****– ........ ***
* ********
000000
I: ID code character
1)
U: Unit symbol
1)
*: Space CR: Carriage return
D: Digit or letter LF: Line feed
1)
depends on scale type; e.g., not all units and characters are available
on scales verified for use in legal metrology (see also next page)
Special Codes
12345678910111213141516171819202122
S t a t ********––******CRLF
H*
L*
*: Space H: Overload
– –: Weight L: Underload
Error Codes
12345678910111213141516171819202122
S t a t *******E*###****CRLF
*: Space # # #: Error code number
