50
Interface Port
Purpose
Your balance is equipped with an interface
port for connection to a computer or other
peripheral device.
You can connect a computer to change,
start and/or monitor the functions of the
balance and the application programs.
Features
Type of interface: Serial interface
Operating mode: Full duplex
Standard: RS-232
Transmission rates:
150, 300, 600, 1200, 2400, 4800, 9600
and 19,200 baud
Parity: Mark, space, odd, even
Character format:
1 start bit, 7-bit ASCII, parity,
1 or 2 stop bits
Handshake:
2-wire interface:
via software (XON/XOFF)
4-wire interface:
Hardware via handshake lines (CTS/DTR)
Operating mode: SBI
Data output format of the balance:
16 or 22 characters
Factory settings:
Transmission rate:
1200 baud (5 1 4)
Parity: Odd (5 2 3)
Stop bits: 1 stop bit (5 3 1)
Handshake: Hardware, 2 characters
after CTS (5 4 2)
Operating mode: Standard SBI (5 5 1)
Print manually/automatically:
Manual after stability (6 1 2)
Preparation
§ see “Pin Assignments" and
“Pin Assignment Chart"
Identification of Non-Verified Digits
Non-verified digits when “e = d"
are automatically identified on the
printout:
Select universal printer:
menu code 5 5 2.
Brackets are used to identify
non-verified digits.
