64
Overview
Specifications
Model LE26P LE225D LE324S LE244S
Weighing capacity g 5/21 40/100/220 320 240
Readability mg 0.002/0.01 0.01/0.01/0.1 0.1 0.1
Tare range (subtractive) g –21 –220 –320 –240
Repeatability (std. deviation) <±mg 0.004 0.02/0.05/0.1 0.2 0.1
Linearity <±mg 0.008 0.03/0.1/0.2 0.3 0.2
Response time (average) s 10 < 6/3 < 3 < 2
Operating temperature range °C 10° to 30° (50° to 86°F)
Allowable ambient
operating temperature °C 5° to 40° (41° to 104°F)
Sensitivity drift within
10 to 30°C <±/K 1 · 10
–6
External calibration weight g 20 (E2) 200 (E2) 200 + 200 (E2)
(of at least accuracy class...) 100 (E2)
Net weight, approx. kg 7.6 7.6 6.5 6.5
Weighing pan size mm 50 d 80 d* 80 d* 80 d*
(inner diameter)
Weighing pan surface cm
2
20 64* 64* 64*
Weighing chamber height
(weighing pan to draft
shield cover) mm 162 232 232 232
Dimensions (W+ D+H)
– Balance mm 213+ 342+270 213+342+ 340 213+ 342+ 340 213+ 342+ 340
– Electronics box mm 134+ 51+ 155 134+ 51 + 155 – –
AC power source/ V~ AC adapter STNG6, 230 V or15 V,
power requirements +15% to – 20% (protection rating IP20)
Frequency Hz 48 – 60
Power consumption (average) VA maximum 16; typical 8
Approx. hours of operation
with the YRB05Z
rechargeable battery pack h 20 20 22 22
Selectable weight units Grams, carats, pounds, ounces, Troy ounces, Hong Kong taels,
Singapore taels, Taiwanese taels, grains, pennyweights,
milligrams, parts per pound, Chinese taels, mommes, Austrian
carats, tola, baht and mesghal
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, odd, mark, or space;
transmission rates: 150 to 19,200 baud; 1 or 2 stop bits;
software/hardware handshake
* Three-sided weighing pan: d = diameter of inner circle.
The cross-hatched section can be fully utilized.
