65
Model LE1003S LE1003P LE623S LE323S LE623P
Weighing capacity g 1010 500/1010 620 320 120/240/620
Readability g 0.001 0.001/0.01 0.001 0.001 0.001/0.002/0.005
Tare range (subtractive) g –1010 -1010 –620 –320 –320
Repeatability (std. deviation) <± g 0.001 0.001/0.01 0.001 0.001 0.001/0.001/ 0.003
Linearity <± g 0.002 0.002/0.02 0.002 0.002 0.002/0.002/0.005
Response time (average) s < 2 < 2 < 1.5 < 1.5 < 1.5
Operating temperature range °C 10° to 30° (50° to 86°F)
Allowable ambient
operating temperature °C 0° to 40° (32° to 104°F)
Sensitivity drift
within +10 to +30°C <±/K 2 ·10
–6
External calibration weight g 1000 (E2) 1000 (E2) 500 (E2) 200 (F1) 500 (F1)
(of at least accuracy class...)
Net weight, approx. kg 6.5 6.5 4.6 4.6 4.6
Weighing pan size mm 110 d
(inner diameter)*
Weighing pan surface* cm
2
120
Weighing chamber height
(weighing pan to draft shield
cover) mm 240 240 50 50 50
Dimensions (W + D + H) mm 213 + 342 + 340 213 + 342 + 153
AC power source/ V~ AC adapter STNG6, 230 V or 115 V,
power requirements +15% to – 20% (protection rating IP20)
Frequency Hz 48 – 60
Power consumption (average) VA maximum 16; typical 8
Approx. hours of operation
with the YRB05Z
rechargeable battery pack h 27
Selectable weight units Grams, carats, pounds, ounces, Troy ounces,
Hong Kong taels, Singapore taels, Taiwanese taels, grains, penny-
weights, milligrams, parts per pound, Chinese taels, mommes,
Austrian carats, tola, baht and mesghal
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, odd, mark,
or space; transmission rates: 150 to 19,200 baud;
1 or 2 stop bits; software/hardware handshake
* Three-sided weighing pan: d = diameter of inner circle.
The cross-hatched section can be fully utilized.
