69
Model LE623S-OCE LE323S-OCE LE623P-OCE
Type BD BL 200 BD BL 200 BD BL 200
Accuracy class
1
) KKK
Weighing capacity, Max
1
) g 620 320 120/240/620
Scale interval d
1
) g 0.001 0.001 0.001/0.002/0.005
Tare range (subtractive) g < 100% of the maximum capacity
Verification scale interval e
1
) g 0.01 0.01 0.01
Minimum capacity, Min
1
) g 0.02 0.02 0.02
Response time (average) s < 1,5
Range of use according to CD
1
) g 0.02–620 0.02–320 0.02–620
Allowable ambient operating
temperature:
– with »isoCAL« function °C 0° to +40° (+32° to +104°F)
– without »isoCAL« function °C +10° to +30° (+50° to +86°F)
Net weight, approx. kg 4.6
Weighing pan size mm 110 d
(inner diameter)*
Weighing pan surface* cm
2
120
Weighing chamber height (weigh-
ing pan to draft shield cover) mm 50
Dimensions (W+D+H) mm 213+342+153
AC power source/ V~ AC adapter STNG6 230 V or 115 V,
power requirements +15% to – 20% (protection rating IP20)
Frequency Hz 48 – 60
Power consumption (average) VA maximum 16; typical 8
Approx. hours of operation
with the YRB05Z reachargeable
battery pack h 27
Selectable weight units Grams, carats
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, odd, mark,
or space; transmission rates: 150 to19,200 baud;
1 or 2 stop bits; software/hardware handshake
1
) CD= Council Directive 90/384/ECC for non-automatic weighing instruments;
applicable to the European Economic Area
* Three-sided weighing pan: d = diameter of inner circle.
The cross-hatched section can be fully utilized.
