SAS RM-MT330-2 User Manual

GB
13
1
Spark plug
11
Trimmer head
21
Throttle trigger lock
2
Choke lever
12
Blade
22
Ignition switch
3
Fuel tank cap
13
Guard
23
Throttle interlock
4
Fuel tank
14
Multi-function screwdriver
24
Backing flange
5
Primer bulb
15
Socket spanner
25
Locking flange
6
Actuating handle
16
S4 Allen key(4mm)
26
Flange cover
7
Air filter cover
17
S5 Allen key(5mm)
27
Nut
8
Fuel mixture bottle
18
Wrench
28
Cutting line
9
Harness
19
Locking knob
10
Suspension point
20
Throttle trigger
ASSEMBLY
WARNING!
Please ensure that the brush cutter is switched off properly and that the engine has stopped
completely before assembly and adjustment.
Assembly of the handle
1.Remove the screws in fixing device and remove the front cover.
2. Place the handle in position and assembly the front cover.
