GB
17
2). Loose the nut with the socket spanner(15) by turning it in clockwise direction (viewed from
above), then remove the nut, Locking flange and the blade from the output shaft.
3). Refit the new blade, aligning the center of the blade.
4). Assembly the Locking flange and then tighten the nut.
5). Remove the Multi-function screwdriver (14).
Replace the cutting spool
1). Insert the Multi-function screwdriver (14) into the semicircular opening on the back side of
blade/ spool to prevent turning of output shaft.
2). Loose the cutting spoolby turning it in clockwise direction (viewed from above).
3). Screw new cutting spool onto the thread of output shaft by turning it in anti-clockwise
direction (viewed from above)
4). Remove the Multi-function screwdriver (14).
WARNING!
Never use non-recommended cutting attachments and appropriate guards and their location.
The non approved cutting attachments may cause serous injure during working.
OPERATION
Before use
Please always read the instruction manual carefully and check the machine before operating.
