GB
15
Fix the guard with 4 bolts and nuts by means of the S4 Allen key and open-end wrench.
And then tighten the 2 bolts and nuts as shown in figure.
NOTE: The guard has two mounting positions. The position A was for grass trimmer and the position B
was for brush cutter.
Position A Position B
WARNING!
Please check the blade and output shaft before each adjusting or assembly, it must be
correctly assembled and running smoothly.
CAUTION!
When installing the Locking flange, ensure that the concave side is properly assembled
