Item No. Part No. Description Qty.
1 PDG.60024.00 PLATE, TOP DRUM 1
2 PDG.6A001.00 SUBASSEM, DRUM SHEAVE 1
3 NB.13.116 SCREW, FLAT HEAD SOCKET CAP M6 -1.0 X 20 8
4 PDG.2A001.00 SUBASSEM, PTO TENSIONER 1
5 NB.12.108 SCREW, SOCKET HEAD CAP M6 -1.0 X 12 ZINC 8
6 PDG.6A003.00 SUBASSEM,TOP BELT IDLER 1
7 PDG.6A004.00 SUBASSEM, TOP BELT TENSIONER 1
8 PDG.6A002.00 SUBASSEM, INTERMEDIATE SHEAVE 1
9 NB.12.249 SCREW, SOCKET HEAD CAP M12-1.75 X 25 12.9 3
2 PDG.6A001.00
Rotate spindle so it lines up as in the picture. Fasten #2 with #3 first, then assemble 1
3NB.13.116 Red LocTite 263, Torque to 35 ft/lb sq 8
5 NB.12.108 AFTER PTO BELT IS TENSIONED PROPPERLY, Blue LocTite 243 8
7 PDG.6A004.00
Large(M20) Bolt: Red LocTite 263, Torque 80 ft-lbf
Small bolts: leave loose, until Top belt is tensioned, then use Blue LocTite 242
8 PDG.6A002.00 Install with spacer in the correct position. 1
9NB.12.249 Red LocTite 263, Torque to 80 ft/lb sq 3
