4
2
1
3
5
Install O-Ring before
inserting bolt and with a
dab of grease
SHEET 1 OF 1
SCALE: 1:2
WEIGHT: .70kg
5
4
3
2
1
PDG 6000
Top Belt Idler Assembly
