Sase PDG 6000 - Page 53

Item No. Part No. Description Quantity
1 PDG.60028.00 IDLER, TOP BELT 1
2 PDG.20220.00 BEARING, 3204-2RS 1
3 PDG.60073.00 SCREW, MODIFIED SOCKET HEAD M20-2.5 1
4 PDG.60027.00 BASE, TOP BELT IDLER 1
5 PDG.20215.00 O-RING, M30 1
PDG.6A003.00 SUBASSEM, TOP BELT IDLER 1
3 PDG.60073.00
Red LocTite 263, Torque 80 ft-lbf into the top plate.
1
Top Idler
Top Idler Supplemental
