Sase PDG 6000 - Page 47

Item No. Part No. Description Qty.
1 NB.12.116 SCREW, SOCKET HEAD CAP M6-1.0 X 20 12.9 ZINC 16
2 PDG.60032.50 RETAINER, OUTER SUSPENSION DUAL BEARING 1
3 PDG.60033.50 RETAINER, INNER SUSPENSION BEARING DUAL 1
4 PDG.20224.00 BEARING, 61818-2RS 2
5 PDG.60030.00 SPINDLE, STATIONARY DRUM 1
6 PDG.60035.00 SHEAVE, STATIONARY DRUM 1
7 PDG.60060.00 SPACER, INNER SUSPENSION BEARING 1
8 PDG.60059.00 SPACER, INNER DRUM SPINDLE BEARING 1
PDG.6A001.00 SUBASSEM, DRUM SHEAVE 1
1
NB.12.116
Red LocTite 263
8
1
NB.12.116
8
3
PDG.60033.50 1
5
PDG.60030.00 1
Drum Sheave
Drum Sheave Supplemental
These parts are installed at the top plate 'upper level'.
Shown here for proper stack-up
