Sase PDG 6000 - Page 49

Item No. Part No. Description Qty.
1 NB.20.107 LUGNUT, M12-1.5 5
2 PDG.60026.00 AXLE, INTERMEDIATE 1
3 PDG.60025.00 SHEAVE, INTERMEDIATE 1
4 PDG.20209.00 SPACER, PTO HUB 1
5 PDG.20201.00 HUB 1
6 NB.20.108 NUT, HEX FLANGE M20-2.5 1
PDG.6A002.00 SUBASSEM, INTERMEDIATE SHEAVE 1
1
NB.20.107
Red LocTite 263, Torque 60 ft-lbf
5
6
NB.20.108
Red LocTite 263, Torque 150 ft-lbf
1
Intermediate Sheave
Intermediate Sheave Supplemental
