Sase PDG 6000 - Planetary Assembly Parts List

Item No. Part No. Description Qty.
1
NB.50.143
PIN, HARDENED M8 X 26 3
2 PDG.60080.00 AXLE, PLANETARY 40MM (MODIFIED) 1
3
PDG.20201.00
HUB 1
3
NB.82.200
SHORTENED STUD 5
4
PDG.60001.00
SHEAVE, PLANETARY 1
5 NB.20.109 NUT, JAM M12-1.5 (Lugnuts displayed are for a 'future' revision) 5
6
NB.20.106
NUT, HEX FLANGE M20-2.5 (MODIFIED) 1
PDG.6A008.10 Planetary Assembled Short 1
1
NB.50.143
PIN, HARDENED M8 X 26 3
2 PDG.20200.00 AXLE, PLANETARY 40MM 1
3
PDG.20201.00
HUB 1
4
PDG.60001.00
SHEAVE, PLANETARY 1
5 NB.20.109 NUT, JAM M12-1.5 (Lugnuts displayed are for a 'future' revision) 5
6
NB.20.108
NUT, HEX FLANGE M20-2.5 1
PDG.6A008.00 Planetary Assembled 2
3
NB.82.200
Studs removed from hub, shortened, reinserted. 5
5NB.20.109 Red LocTite 263, Torque 60 ft-lbf 5
6
NB.20.106
Red LocTite 263, Torque 150 ft-lbf 1
Planetary Assembly (Short)
Planetary Assembly Supplemental
