Item No. Part No. Description Quantity
1 PDG.20103.00 YOKE, SUSPENSION 4
2 PDG.20109.00 BUSHING, YOKE 4
3 PDG.20102.01 ELEMENT, CENTER STUDDED 1
4 PDG.20100.50 PLATE, DRIVING 1
5 PDG.20101.01 PLATE, DRIVEN 1
6 NB.13.218 SCREW, FLAT HEAD SOCKET CAP M8 -1.25 X 20 8
7 PDG.20104.25 LOCK, SHAMROCK PLATE ASSEM 1
8 NB.13.216 SCREW, FLAT HEAD SOCKET CAP M8-1.25 X 16 7
9 PDG.20106.25 POST, SPRING 4
10 PDG.20106.52 SPRING, DIE BLUE MEDIUM 4
11 NB.40.113 RING, EXTERNAL 1/2" 4
PDG.6A010.00 FLEX HEAD, WITH BLUE SPRING 3
1 PDG.20103.00
Insert bushing first. One side will be flush on the outter edge of metal sheath, one side
will protrude out on the outter edge of metal. The flush side faces the inward in the
assembly.
4
6NB.13.218
Red LocTite 263
8
8NB.13.216
Red LocTite 263
7
PDG 6000 FLEX HEAD SUPPLEMENTAL
