6 POINT LARGE MILLING CUTTERS
Theoretical Assembly
LRM VA30 S Cutter Set - 800.LRM.12/208
Components: 12 Cutters - 630.03.08
208 Spacers - 630.03.06
Attention: There can be a difference in number of spacers, but there must be a clearance of 1/8”
to 3/16” between the supporting segments.
9 INCH CUTTING WIDTH
27 SPACERS
23 SPACERS
27 SPACERS
23 SPACERS 19 SPACERS
15 SPACERS
19 SPACERS
15 SPACERS
