Sase SC8E - Page 48

SC08E
18 POINT STAR CUTTERS
Theoretical Assembly
SS FR 200 Cutter Set - 800.SS.260/00
Components: 260 Cutters - 615.01.04
Attention: There can be a difference in number of spacers, but there must be a clearance of 1/ 8”
to 3/16” between the supporting segments.
29 CUTTERS
29 CUTTERS
36 CUTTERS
36 CUTTERS
29 CUTTERS
29 CUTTERS
36 CUTTERS
36 CUTTERS
