Features
Specifications
SAS6000UTK-7-WIFI
Power Supply : Dual Power 24VAC (18-30VAC,50/60Hz)
or Battery Powered
Terminal Load : 1.0 A per terminal, 2.0A maximum total load
Set point Temperature Range : 41℉ to 95℉(5℃ to 35℃)
Operating Ambient : 32℉ to 122℉ (0℃ to 50℃)
Operating Humidity : 90% non-condensing max
Shipping Temperature Range : 14℉ to +140℉
(-10℃ to 60℃)
Dimensions : 5.9 inch×4.5 inch×1.2inch
(150mm×115mm ×32mm)
Color : White
Apply with various kind of heating and cooling system. Including Single stage,
Multi-stage And Heat Pump
(Up to 3-stage heat, 2-stage cool, with Aux. Or Emergency heat)
Large LCD display with backlight, continuous backlight option
Menu driven programming
Fan switch with on and auto
Permanent user setting retention during power loss, no batteries are required
Optional temperature display of Celsius or Fahrenheit scale
Auto change over
Optional 7 day programming and non-programmable
The screen displays the set temperature, the room temperature and current
time simultaneously
Air filter change indicator
Both vacation mold and hold duration mode available for comfort and energy
saving
UV light change indicator
15 16
