<< Operating Instructions SATA adam 2 >>
EN
VII.2
<< Operating Instructions SATA adam 2 >>
3. Scope of Delivery
Product
Component
SATA adam 2 SATA adam 2
mini
SATA adam
2 display
SATA adam 2 display X X X
SATA adam 2 dock X - -
SATA adam 2 mini dock - X -
One RENATA CR2032 battery is included in the delivery.
4. Technical Design of the SATA adam 2 [1]
[1-1] SATA adam 2 dock connec-
tion module for SATA spray
guns
[1-2] SATA adam 2 mini dock
connection module for SATA
minijet spray guns
[1-3] Regulation wing
[1-4] Ball valve
[1-5] SATA adam 2 display
[1-6] Special O-ring
[1-7] Locking clip
[1-8] Digital display
[1-9] O-ring | Please regularly
lubricate with high per-
formance grease (Art.
No. 48173) - sample tube
included in scope of delivery.
5. Intended Use
The SATA adam 2 and the SATA adam 2 mini as well as the SATA adam 2
display in combination with the respective SATA adam 2 dock connection
module are designed for adjustment and control of the inlet pressure of a
SATA spray gun.
Warning!
• The user is responsible for any damage and accidents caused by im-
proper use!
