Unit 3: Installation
Lt408 Operator Manual
3-4 PN: 9001152A
Figure 3-3, Printer Mounting
Figure 3-4, Printer Connection
ATTENTION: Figure 3-4 displays the printer interfaced with a host computer.
However, the printer may also be interfaced with a PLC, keyboard, scanner, etc.
OR
Applicator
Host Computer
Breaker Box
Interface Card
Power Cord
Printer
EXT Interface
Interface Cable
To Next Page
