Unit 4: Printer Configuration
Lt408 Operator Manual
4-34 PN: 9001152A
This printer does not have a dispenser assembly, thusly this screen should be ignored.
Enables the printer’s serial number to be recorded within its memory.
Enables the revision number of the main circuit board to be recorded within its memory.
Enables the revision number of the interface board to be recorded within its memory.
Initiates test printing.
If the YES option is select from the previous screen, this menu allows the test print type
to be selected.
Enables the print size to be selected.
Initiates test printing activity.
FACTORY MODE (TABLE 4-9)
MENU DESCRIPTION
DISPENSE COUNTER
X.X M
SERIAL NO.
S/N XXXXXXXX
MAIN PCB
REVISION
REV X.X
INTERFACE BOARD
REVISION
REV X.X
TEST PRINT
YES NO
TEST PRINT MODE
FACTORY
AIAG
SCALE
RIGHT
LEFT
GRAY
N-PATTERN
PRINT SIZE
SMALL LARGE
TEST PRINT
PRESS ENTER KEY
