4. Firmly press down making sure the latch is flat with
the ribs (A) on the storage bin.
5. Switch hands and repeat Steps 2 through 4 for the
latch on the opposite side of the storage bin.
6. Reverse these steps in order to remove the
storage bin.
The contents of the bin should never weigh more than
1.5 lbs (0.7 kg).
Always make sure to close and latch the bin before
driving.
Overhead Console (Without Rail)
If your vehicle has an overhead console without the rail
system, it has two reading lights, a courtesy light,
and a switchbank. See Overhead Console Switchbank
on page 3-21 for more information.
Floor Console Storage Area
If your vehicle has a storage compartment located on
the front console below the front cupholders. Pull up and
then forward on the handle to open the storage
compartment.
2-52
