Step 1
Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å
Assemble your unit on a carpeted fl oor or on the empty
carton to avoid scratching your unit or the fl oor.
å
Push sixteen HIDDEN CAMS (MM2) into the ENDS (A2
and B), UPRIGHTS (C2 and D2), and BOTTOMS (G2 and H).
Then, insert the metal end of a CAM DOWEL (NN2) into each
HIDDEN CAM.
A2
B
C2
D2
G2
H
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
Arrow
(16 used)
MM2
NN2
402375 www.sauder.com/servicesPage 6
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1660
to watch a video on how to assemble your unit.
