Step 8
å
Carefully stand the assembly upright.
å
Fasten the RIGHT END (A) to the MODESTY PANEL (H).
Tighten two TWIST-LOCK® FASTENERS.
å
NOTE: Be sure to support the MODESTY PANEL until it is
fastened to the UPRIGHT (C).
å
Fasten the MODESTY PANEL (H) to the UPRIGHT (C).
Use two BLACK 1-7/8" FLAT HEAD SCREWS (LL).
408761 www.sauder.com/servicesPage 12
Pro Tip: Lift with your
legs. And, you know,
your arms.
Surface without
TWIST-LOCK®
FASTENERS
C
H
A
Edge with TWIST-LOCK® FASTENERS
Curved edge
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
LL
To Next Page
