å
Fasten the RIGHT END (A) to the TOP (D) and MODESTY
PANEL (F). Tighten fi ve HIDDEN CAMS.
Step 11
Notched edge
Arrow
Minimum
190 degrees
Maximum
210 degrees
408995 www.sauder.com/servicesPage 16
A
D
F
