Step Step 2
411312www.sauder.com/services
Page 7
GOLD 5/16" FLAT HEAD SCREW
(4 used for the RAILS)
3S
Remember:
Righty tighty.
Lefty loosey.
A2
B2
7A
BLACK 9/16" LARGE HEAD SCREW
(2 used for the ROD HANGERS)
1S
Long fi nished edge
Roller end
Long fi nished edge
å
Fasten the CABINET RIGHT (40CA) and CABINET
LEFT (40CB) to the ENDS (A2 and B2). Use four GOLD
5/16" FLAT HEAD SCREWS (3S).
å
Fasten the ROD HANGERS (7A) to the ENDS (A2 and B2).
Use two BLACK 9/16" LARGE HEAD SCREWS (1S).
Roller end
To Next Page
