Step Step 13
Page 18
å
Fasten the DRAWER BRACE (M65) to the DRAWER FRONT (L). Tighten one
HIDDEN CAM.
å
Fasten the DRAWER BACK (D175) to the DRAWER SIDES (D50 and D51) and
DRAWER BRACE (M65). Use fi ve BLACK 1-9/16" FLAT HEAD SCREWS (30S).
1
2
1
st
2
nd
Surface with
HIDDEN CAM
D175
D51
D50
L
VIEW THE T-SLOT BOX VIDEO
30S
Start each screw a few turns before
completely tightening any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(5 used in this step)
M65
M65
To Next Page
