Step 8
å
Carefully lay your unit onto its front edges.
å
Insert two METAL PINS (1R) into the LOWER BRACE (N).
å
Fasten the LOWER BRACE (N) to the ENDS (A and B).
Tighten two HIDDEN CAMS.
å
NOTE: Be sure the METAL PINS in the LOWER BRACE
insert into the holes in the ENDS.
413852 www.sauder.com/servicePage 12
Arrow
Minimum
190 degrees
Maximum
210 degrees
Surface with HIDDEN CAMS
N
B
A
1R
To Next Page
