Fasten the BACK PANEL (I2) to the HEADBOARD (E).
Tighten three HIDDEN CAMS.
å
Fasten the LOWER UPRIGHT (C2) to the BACK PANEL (I2).
Tighten two HIDDEN CAMS.
Step 13
413852www.sauder.com/service
Page 17
Arrow
Minimum
190 degrees
Maximum
210 degrees
Roller end
Finished edge
Unfi nished surface
C2
E
I2
These HIDDEN CAMS are
closer to the long edge.
Headboard on the RIGHT
