Sauder 413852 - Page 23

Step 19
å
Fasten the FOOTBOARD (F) to the FRONT PANELS (G2
and H2) and BACK PANEL (I2). Tighten six HIDDEN CAMS.
å
NOTE: Be sure the METAL PIN in the FOOTBOARD inserts
into the hole in the LOWER FRONT PANEL.
Arrow
Minimum
190 degrees
Maximum
210 degrees
G2
H2
I2
F
Rounded edge
Headboard on the LEFT
413852www.sauder.com/service
Page 23
Surface without holes
