Step 18
å
Fasten the LOWER FRONT PANEL (H2) to the
HEADBOARD (E) and LOWER UPRIGHT (C2). Tighten
two HIDDEN CAMS.
å
NOTE: Be sure the METAL PIN in HEADBOARD inserts
into the hole in the LOWER FRONT PANEL.
å
Fasten the UPPER FRONT PANEL (G2) to the
HEADBOARD (E) and LOWER UPRIGHT (C2). Tighten
three HIDDEN CAMS.
Arrow
Minimum
190 degrees
Maximum
210 degrees
Finished edge
Surface without HIDDEN CAMS
Surface without HIDDEN CAMS
C2
Unfi nished edge
G2
E
H2
Headboard on the LEFT
