Sauder 413852 - Page 9

å
Fasten the UPRIGHTS (D) to the TOP (J). Tighten two
HIDDEN CAMS.
å
Fasten the SHELF (L) to the UPRIGHTS (D). Use four
BLACK 1-7/8" FLAT HEAD SCREWS (2S).
Step 5
413852www.sauder.com/service
Page 9
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
D
L
D
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Surface with
HIDDEN CAMS
Surface with HIDDEN CAM
J
Angled edge
Angled edge
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S
