Step 6
å
Fasten four ANGLE BRACKETS (5G) to the SHELF BRACE (M).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å
NOTE: Be sure the edges of the ANGLE BRACKETS are even
with the edge of the SHELF BRACE.
å
Fasten the SHELF BRACE (M) to the SHELF (L). Use four
BLACK 9/16" LARGE HEAD SCREWS (1S).
413852 www.sauder.com/servicePage 10
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
5G
M
M
L
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
Angled edge
These surfaces should be even.
