Step 8
å
NOTE: You will need to hold the SUPPORT (Q) o the ground or
place packing material under the SUPPORT while fastening it to
the SMALL SUPPORTS (X).
å
Fasten one of the SUPPORTS (Q) with LARGE SUPPORT (Y) to the
SMALL SUPPORTS (X) on the FOOTBOARD RAILS (N2 and O2).
Use four BLACK 1-15/16" FLAT HEAD SCREWS (113S).
å
NOTE: The LARGE SUPPORT (Y) should be o the ground and
facing toward the FOOTBOARD (R).
414129 www.sauder.com/servicePage 12
Don't worry. It isn't
Rome. This can be built
in a day.
Y
N2
O2
X
X
Q
R
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S
