Fasten the SUPPORTS (Q) to the LARGE SUPPORTS (Y),
FOOTBOARD (R), and HEADBOARD (S). Use twenty
BROWN 1" FLAT HEAD SCREWS (12S).
å
NOTE: Use the center two holes in the SUPPORTS (Q) that
will be fastened to the LARGE SUPPORTS (Y).
å
NOTE: Start each SCREW a few turns before tightening
any of them.
Step 3
414129www.sauder.com/service
Page 7
Y
R
S
Y
Q
Q
Q
Q
BROWN 1" FLAT HEAD SCREW
(20 used in this step)
12S
Surface with more holes
Unfi nished edge
Unfi nished edge
To Next Page
