Step 6
å
Fasten the LOWER LEFT END (D) to the SHELF (G).
Tighten two HIDDEN CAMS.
414356 www.sauder.com/servicesPage 10
Arrow
Minimum
190 degrees
Maximum
210 degrees
D
Notched edge
Surface with
HIDDEN CAMS
G
