Sauder 414356 - Step 8: Attaching Lower Right End and Moldings

Step 8
å
Fasten the LOWER RIGHT END (C) to the BOTTOM (F)
and SHELF (G). Tighten four HIDDEN CAMS.
å
Slide the LOWER END MOLDINGS (P) onto the notched
edges of the LOWER ENDS (C and D).
å
* U.S. Patent No. 5,499,886
414356 www.sauder.com/servicesPage 12
Arrow
Minimum
190 degrees
Maximum
210 degrees
Notched edge
Notched edge
C
D
P
P
Slide the LOWER END
MOLDINGS (P) onto
the notched edges.
G
F
Surface without
HIDDEN CAMS
