Sauder 418630 - Step 4: Panel and Shelf Connection

Step 4
å
Fasten four ANGLE BRACKETS (27G) to the PANEL (F).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å
NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edge of the PANEL.
å
Fasten the PANEL (F) to the SHELF (D). Use four BLACK
9/16" LARGE HEAD SCREWS (1S) through the ANGLE
BRACKETS on the PANEL and into the SHELF.
418630 www.sauder.com/servicesPage 8
F
D
27G
F
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
Rounded edge
