Sauder 418630 - Step 5: Connect Left End Assembly

å
Fasten the SHELF (D) and PANEL (F) to the LEFT END (B).
Tighten four HIDDEN CAMS.
Step 5
418630www.sauder.com/services
Page 9
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Surface without HIDDEN CAMS
F
D
B
Suface with HIDDEN CAMS
