Sauder 419954 - Assembly Tools Required; Part Identification

Table of Contents Assembly Tools Required
2-3
4
5-32
33-37
38-43
44-46
47
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
419954 www.sauder.com/servicesPae 2
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identifi cation to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C BOTTOM (2)
D RIGHT UPRIGHT (1)
E LEFT UPRIGHT (1)
F BACK (2)
G MODESTY PANEL (1)
H RIGHT FRONT LEG (2)
I END MOLDING (4)
J BOTTOM MOLDING (2)
K BACK MOLDING (2)
L PENCIL DRAWER FRONT (1)
M PENCIL DRAWER MOLDING (1)
N SHELF (1)
O SHELF FRONT (1)
P LEFT FRONT LEG (2)
Q RIGHT REAR LEG (2)
R LEFT REAR LEG (2)
S MODESTY PANEL MOLDING (2)
T EXTENSION BLOCK (2)
U TOP (1)
V SMALL DRAWER FRONT (4)
W LARGE DRAWER FRONT (2)
B37 PENCIL DRAWER BOTTOM (1)
D24 SMALL DRAWER RIGHT SIDE (4)
D25 SMALL DRAWER LEFT SIDE (4)
D28 LARGE DRAWER RIGHT SIDE (2)
D29 LARGE DRAWER LEFT SIDE (2)
D78 LARGE DRAWER BACK (2)
D109 SMALL DRAWER BACK (4)
D425 PENCIL DRAWER BACK (1)
D427 PENCIL DRAWER RIGHT SIDE (1)
D428 PENCIL DRAWER LEFT SIDE (1)
D506 PENCIL DRAWER BOX FRONT (1)
D707 LARGE DRAWER BOTTOM (2)
D716 SMALL DRAWER BOTTOM (4)
