Sauder 419954 - Step 17

Step 17
419954www.sauder.com/services
Pae 21
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thorouhly before
assemblin. Disassembly of lued
parts is extremely di cult.
Caution
!
54M
15F
å
NOTE: You will need someone's help in this step.
å
First, fi ll eiht small holes in the TOP (U) 1/4 to 1/2 full with GLUE (54M). Then,
insert eiht WOOD DOWELS (15F) into the holes. Wipe away the excess GLUE.
å
Now, fi ll the holes in the LEGS (H, P, Q, and R) 1/4 to 1/2 full with GLUE (54M).
å
Fasten the ENDS (A and B) and UPRIGHTS (D and E) to the TOP (U). Tihten
eiht TWIST-LOCK® FASTENERS.
å
NOTE: Be sure the WOOD DOWELS in the TOP insert into the LEGS. Wipe
away the excess GLUE.
å
Fasten the UPRIGHTS (D and E) to the MODESTY PANEL (G). Use four BLACK
1-15/16" FLAT HEAD SCREWS (113S).
15F
U
(8 used)
A
B
D
E
H
P
Q
R
Q
H
P
R
G
BLACK 1-15/16" FLAT HEAD SCREW
(4 used for the MODESTY PANEL)
113S
NOTE: Before beinnin this step, be sure to separate the BLACK
1-9/16" FLAT HEAD SCREWS (30S) from the BLACK 1-15/16"
FLAT HEAD SCREWS (113S). Do not confuse these SCREWS.
