Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
BLACK 1-3/4" PAN HEAD SCREW - 10
13
BLACK 1" PAN HEAD SCREW - 4
14
BLACK 1" FLAT HEAD SCREW - 8
15
BLACK 1/2" MACHINE SCREW - 4
17
BLACK 1/2" FLAT HEAD SCREW - 12
19
BLACK 5/16" MACHINE SCREW - 1
21
BLACK 11/16" FLAT HEAD SCREW - 4
16
BLACK 1/2" PAN HEAD SCREW - 22
18
BLACK 1/2" MACHINE SCREW - 4
20
NUT - 1
11
WOOD DOWEL - 4
8
METAL BRACKET - 6
9
PULL - 2
10
TOOL - 1
12
Page 4 www.sauder.com 420203
HIDDEN CAM - 12
5
SMALL HIDDEN
CAM - 12
6
CAM SCREW - 24
7
4
EXTENSION SLIDE - 2
3
EXTENSION RAIL - 2
(EXTENSION SET SHOWN SEPARATED)
1
LEFT RAIL - 1
2
RIGHT RAIL - 1
