Step 2
å
Fasten the LEFT RAIL (1) and one of the SMALL
EXTENSION BLOCKS (M) to the LEFT UPRIGHT (H)
exactly as shown. Use two BLACK 11/16" FLAT
HEAD SCREWS (16).
å
NOTE: Find the back hole fi rst. Then, slide the inner
cartridge of the LEFT RAIL in to fi nd the other hole that
lines up with the hole in the SMALL EXTENSION BLOCK
and LEFT UPRIGHT. Turn a SCREW into this hole.
Page 6 www.sauder.com 420203
BLACK 11/16" FLAT HEAD SCREW
(2 used in this step)
16
H
M
1
These edges
should be even.
This hole is closer
to this edge.
Line up the
back hole fi rst.
Finished surface
1
To Next Page
