Step 4
å
Fasten the CENTER LEG (C) to the CENTER END (F) and
CENTER UPRIGHT (G). Use four BLACK 1/2" PAN HEAD
SCREWS (18) through the METAL BRACKETS on the CENTER
LEG and into the CENTER END and CENTER UPRIGHT.
å
Finish fastening the CENTER LEG (C) to the CENTER END (F)
and CENTER UPRIGHT (G). Use four BLACK 1-3/4" PAN
HEAD SCREWS (13).
å
Turn two CAM SCREWS (7) into the CENTER END (F).
Page 8 www.sauder.com 420203
BLACK 1/2" PAN HEAD SCREW
(4 used in this step)
18
BLACK 1-3/4" PAN HEAD SCREW
(4 used in this step)
13
G
C
F
Surface with holes
Surface with
fewer holes
Edge without holes
7
To Next Page
