NOTE: Stand the UPRIGHT (D2) in place to be sure you
are drilling through the correct holes in the TOP (E2).
å
There are four pre-drilled holes in the top surface of the
TOP (E2). Finish drilling out two holes with your electric
drill and 1/4" drill bit.
å
Fasten the UPRIGHT (D2) to the TOP (E2). Use two
BLACK 1-15/16" FLAT HEAD SCREWS (113S).
å
Fasten the UPRIGHT (D2) to the LARGE SHELF (I).
Tighten two TWIST-LOCK® FASTENERS.
Step 3
Find the correct pre-driled holes that
line up with the UPRIGHT (D2) and drill
through the top surface of the TOP (E2).
These four holes must be here.
E2
I
D2
422427www.sauder.com/services
Page 9
BLACK 1-15/16" FLAT HEAD SCREW
(2 used in this step)
113S
LARGE DOOR ON LEFT
This locator hole
must be here.
