Sauder 535782 - Page 13

Step 9
Page 13
å
Fasten the HINGES (23) to the DOORS (T and U). Use
twelve 1/2" FLAT HEAD SCREWS (35).
å
Fasten the STRIKE PLATES (29) to the DOORS (T and U).
Use four SMALL 1/2" FLAT HEAD SCREWS (40).
T
U
1/2" FLAT HEAD SCREW
(12 used for the HINGES)
35
29
29
SMALL 1/2" FLAT HEAD SCREW
(4 used for the HINGES)
40
23
23
