Push eight HIDDEN CAMS (1F) into the BOTTOMS (G2).
Then, insert the metal end of a CAM DOWEL (2F) into
each HIDDEN CAM.
Step 2
416513www.sauder.com/services
Page 9
G2
G2
(8 used)
Arrow
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
2F
1F
