Sauder Craft Armoire - Product Identification and Tools; Part Identification; Assembly Tools Required

Table of Contents Assembly Tools Required
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
2-3
4-5
6-24
25-28
29-32
33-34
35
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D FIXED SHELF (1)
E BOTTOM (1)
F BACK (1)
G RIGHT DOOR (1)
H LEFT DOOR (1)
I PULL-OUT TOP (1)
J3 PULL-OUT BACK (1)
K FLIP-UP TOP (1)
L OUTER UPRIGHT (2)
M INNER UPRIGHT (2)
N SHELF UPRIGHT (1)
O SLIDING SHELF (1)
P SLIDING SHELF BACK (1)
Q ADJUSTABLE SHELF (6)
R LEG (1)
S FRONT MOLDING (1)
T RIGHT MOLDING (1)
U LEFT MOLDING (1)
V LEG STOP (1)
