Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
QQ
KNOB - 2
LEVELER - 4
LL
PROPEL NUT - 4
MM
NN
LEVELER BRACKET - 4
MAGNETIC CATCH - 1
KK
GROMMET CAP - 1
PP
HH
TWIST-LOCK
®
FASTENER - 14
FLIP-UP TOP
HINGE - 2
JJ
CORD CLIP - 1
RR
HINGE - 4
II
GROMMET - 1
OO
(EXTENSION SET SHOWN SEPARATED)
EXTENSION RAIL - 2
W
EXTENSION SLIDE - 2
X
(EXTENSION SET SHOWN SEPARATED)
LOCKING
EXTENSION SLIDE - 2
ZY
LOCKING
EXTENSION RAIL - 2
CASTER - 2
FF
35AW
CABINET RIGHT - 1
35AY
DRAWER RIGHT - 1
35AZ
DRAWER LEFT - 1
35AX
CABINET LEFT - 1
GG
CASTER BRACKET - 2
158097 www.sauder.com/servicesPage 4
OUTLET - 1
1D
