Fasten the LEFT MOLDING (U) to the LEFT END (B). Use two
BLACK 2" PAN HEAD SCREWS (YY).
å
Fasten the FIXED SHELF (D) and BOTTOM (E) to the LEFT
END (B). Tighten four TWIST-LOCK® FASTENERS.
How to use the SAUDER TWIST-LOCK
®
FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Finished edge
Finished edge
Finished edge
Unfi nished surface
Surface with TWIST-LOCK®
FASTENERS
Finished surface
B
D
E
S
U
Dowel end
BLACK 2" PAN HEAD SCREW
(2 used in this step)
YY
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
To Next Page
